| Video/Audio Input | Video Compression: H.264 |
| Video Input: 4-channel |
| OSD: Text, Time/date, car ID,GPS info |
| Audio Compression: G.726 |
| Audio Input: 4-ch |
| Audio Input Interface: Aviation Interface (linear electrical level, 1 kΩ) |
| Two-way Audio: 1 Aviation Interface (Linear electrical level, 1KΩ) |
| Video/Audio Output | Live View Resolution: 4CIF (PAL: 704x576, NTSC: 704x480) |
| VGA Output: 1-ch, resolution: 800x600/60Hz, 800x600/75Hz, 1024x768/60Hz |
| Recording resolution: D1/CIF/QCIF,up to 2ch D1+2ch CIF |
| Video output: 1-ch, Aviation Interface |
| Frame Rate: 25(P)/30(N) fps Video Bit Rate: 32Kbps~2048Kbps, or user-defined (Max.3Mbps) |
| Stream Type: Video/Video&Audio |
| Audio Output: 1-ch RCA(Linear electrical level, 600Ω) |
| Audio Bit Rate: 16kbps |
| HDD/SD card | Interface Type: 1 pluggable SATA interfaces |
| Capacity: Up to 2TB capacity |
| Technical Patent: Hard disk vibration-proof and bracing technology |
| SD card: 1 SD card support up to 32G(for mirror) |
| Alarm | Alarm input/output : 6ch switch-value input/1ch switch-value output |
| Alarm record: Pre-record 15seconds,post record(30s~30min) |
| Alarm for remaining HDD space, Support for remaining HDD space alarm |
| Function alarm: GPS speeding, acceleration, Motion Detection |
| Wireless Transmission | Embedded 3G wireless transmission module, WCDMA, CDMA2000, TD-SCDMA system for selection;Compatible with GPRS, EDGE;Embedded Wi-Fi module; |
| Interface | Network Interface: 1 RJ45 10M/100M adaptive Ethernet Interface |
| 3G(option): Built-in WCDMA/CDMA2000 module |
| USB Interface: 1 USB 2.0 interface |
| Serial Interface: 1 RS-232 interface; 1 RS-485 interface |
| Alarm Input: 6-ch switch-value signal |
| Alarm Output: 1-ch switch-value signal |
| Remote Control: IR Remote Control |
| GPS(option): Built-in GPS Module, |
| G-sensor :Built-in |
| General | Power Input: 6~36V DC adaptive |
| Power Output: 12V/2A DC, 5V/0.5A DC output |
| Power Off Delay: Patent UPS technology, can working 3~5 seconds after |
| power shut down suddenly |
| Power On/Off: | 1. ACC power on/off |
| 2. HDD lock power on/off |
| 3. Delay power on/off |
| 4. Scheduled power on/off |
| Consumption: ≤10W (working); <0.5 W(standby) |
| Working Temperature: -25°C~+60°C(-13°F~140°F) |
| Working Humidity: 10%~95% |
| Dimensions: 19.8cm (L) * 15.8cm (W) * 6.5cm (H) |
| Weight: 3500g(7.7lbs) |
| Note: The specs are subject to change without prior notice. |
